T10 Right and Left Hand Leadscrew Tr10x1 Tr10x1.5 Tr10x2 Tr10x3 Tr10x4 Tr10x5 Tr10x6 Tr10x8 Tr10x10 Tr10x12 Twin-lead Lead Screw
Tr10*1-Tr10*12
$24.99
Skip to product information
T10 Right and Left Hand Leadscrew Tr10x1 Tr10x1.5 Tr10x2 Tr10x3 Tr10x4 Tr10x5 Tr10x6 Tr10x8 Tr10x10 Tr10x12 Twin-lead Lead Screw
$24.99
Product Overview
T10 right and left hand lead screwTr10x1 Tr10x1.5 Tr10x2 Tr10x3 Tr10x4 Tr10x5 Tr10x6 Tr10x8 Tr10x10 Tr10x12 twin-lead lead screw
ALM is one of the world's three hard-rolled cold rolling screw rod technology holders. ALM lead screws fit nicely, run smoothly, left and right motion softness consistent, dynamic smoothness is good, lead screw assemblies transmission efficiency is higher, torque is smaller, motor load is smaller. Both cold rolling and grinding manufacturing technology are available to provide the corresponding products according to customers' requirements.
|
Available lead screw material
|
ASTM1045,SUS303,SUS304,SS316,SS316L
|
|
Available lead nut material
|
Brass,Tin bronze,Phosphor bronze,Aluminum bronze,POM,PEEK,nylon,POK,Stainless steel, 1045,Zinc alloy,Brass+Plastic,Aluminum
alloy+Plastic,Brass+Steel,Self lubricating(No oil type) |
|
Available surface coating
|
Zinc-plated,nickel plated,hard chromium plated,fluorine coated,tungsten disulfide,black chorme plated
|
|
Quality standard
|
ISO9001:2015,CE certificate,RoHS and reach compliance
|
|
Clearance
|
7e,higher precision is available upon request |
|
Custom Services
|
Customized nuts and end machining are available upon drawing
|
Our Advantages
●Low friction
●High speed
●Wear resistance
●Corrosion resistance
|
Free service
|
Performance testing
|
|||
|
Technical solution
|
||||
|
Custom service
|
C45,Stainless steel and other customized materials
|
|||
|
Surface treatment
|
||||
|
Custom lead nut and shaft end machining
|
||||
Lead Screw Dimension
